YOU CAN COUNT ON OUR EXPERTISE
| Model No. | RTCH-0202A | RTCH-0404A | RTCH-0808A |
|---|---|---|---|
| Number of Lines | 2 | 4 | 8 |
| Fluid | Air | Air | Air |
| Max. Operating Pressure | 3~9.99kgf/㎠ | 3~9.99kgf/㎠ | 3~9.99kgf/㎠ |
| Max. RPM | 900rpm | 900rpm | 900rpm |
| Operating Temperature | 0~70℃ | 0~70℃ | 0~70℃ |
| Weight | 0.16kg | 0.40kg | 0.76kg |
| MODEL NO | Download | 주문 | ||
|---|---|---|---|---|
| 2D | 3D | |||
| RTCH-0202A |  |
 |
 |
 |
| RTCH-0404A | |
|
|
|
| RTCH-0808A | |
|
|
|
